Printed Circuit Board Assembly
We produce PCB from single-sided PCB, double-sided PCB, and multi-layer PCB for up to 12 layers. With the association of our assembly house, Surface Mount Technology ( SMT ) and wave soldering, we are able to provide our customers Printed Circuit Board Assembly and perform functional test.
SYSTEM CONTROLLER
OUTDOOR ADVERTISING ANNIMATION SYSTEM
DOUBLE-SIDED
FR4
Assembly : Surface Mount Technology and wave soldering
Male and female power connectors
FOR MAINFRAME, 3 POWER AND 46 SIGNALS
Connector Body :Plastic Injection parts, tooling engineering by Tahoe
Material : PPS
Pin contact : Brass 360
Printed Circuit Board Assembly :Flex PCB with edge card connector
Assembly : Surface Mount Technology
MEDICAL MONITORING DEVICE
Housing :Plastic Injection parts, tooling engineering by Tahoe
Material : Cycology C6800, ABS
PCB : FR4, 4-Layer boards with gold plated 10u
Assembly : Surface Mount Technology
Manufacturing capability
Layer Count
2-12
Board Thickness
0.3 mm ~ 3.2 mm
Max board size
16 x 22 (inch)
Max copper thickness
3 OZ
Min Line Width/Spacing
3/3 mil
Min. Hole Size
0.2 mm (machine drilled)
0.1 mm (laser drilled )
IMPEDANCE CONTROL
10%
BLIND/BURIED HOLE
SEQUENTIAL LAMINATION, LASER DRILL VIA
HASL (Leaded )
HASL (Lead free)
SURFACE FINISH
Electroless Nickel Imersion Gold (Lead free)
Electrolytic. hard gold ( Lead free )
Entek(OSP), (Lead free)
Immersion Silver (Lead free)
